Horti Line LED

GROW LIGHT SPECIFICATIONS

 SOME APPLICATIONS

  • Greenhouses
  • Seeds
  • Tissues
  • City Farming
  • Indoor plants
  • Multilayer growths
  • and many more..



PRODUCT FEATURES

 -        Taiwan Brand LED chips ensuring high efficiency, low consumption and stability

-        Transparent PMMA Lens with excellent light penetration. 90° Beam Angle

-        Multiple wavelengths are available for OEM. requests

-        Input-Voltage: AC100-AC 240 V. Power Usage 56 Watt

-        External driver high Power Factor >0,95 high conversion efficiency, stable and high safety factor

-        Aircraft Aluminum Quality, good heat dissipation

-        Saves 60-80 % energy over traditional HPS light

-        No toxic substances such as lead, mercury and other inorganic chemicals

-        Green environmental protection



OPTICS: 90 Beam Angle

Why Usage of RED and BLUE:

Exposure time control over 4 hours every day promoting the accumulation of organic substance,

enhancing photosynthesis, releasing oxygen, accumulation of organic protein, substantially help seeding development; rapid growth of plants, shortening the plant growth cycle.



DIMENSION  DESCRIPTION



Input Voltage

AC100V-240V



Power

56W±5%



Power Factor

≥0.9



Luminous Surface

Clear Cover



Beam Angle

90°



Led Quantity

56 pcs 1 watt type





Red

Yellow

Blue

Wavelength (nm)

625-660

585-595

440-450

LuminousLm

1000 Lm±5%



Ratio

R:B:Y=5:1:1



IP Grade

IP65



Life Span

≥35000h






















Spectrum Power (%) distribution chart

 Light Characteristics influence plants over lifetime. Both plant growth (photosynthesis and development (morphology)



-       Light intensity on certain moment

-       Light sum over time

-       Light at which moment of the day

-       Light/dark period per day

-       Light quality (spectrum)



PPFD DATA

  • Micromole(s) or Micromole/m2 is the unit for light for plants, corrected for the 400-700 nm area

Height :10cm; Unit: µmol/m^2*s













32

73

66

64

73

69

69

78

94

129

273

255

230

166

229

202

249

277

51

130

122

144

115

157

122

150

121

Height :30cm; Unit: µmol/m^2*s













29

35

43

45

50

45

53

45

29

34

49

60

54

58

62

58

56

31

36

56

67

63

72

75

67

61

36

34

47

53

50

59

61

60

49

32

  • Lux/Lumen is the unit for Light used for humans, this is corrected for the human eye sensitivity curve



PHOTOMETRIC DATA

LIGHT ATTENUATION TEST:

Test Time

Decay rate

500 hrs

0%

1000 hrs

0%

2000 hrs

1%

4000 hrs

2.4%

6000 hrs

4%








  • Different variations of Red, Blue and Yellow have different influence on growth of horticultural products. Our light bars can be designed according your seasonal period and choice of vegetables or fruits.
  • Experience on tomatoes has proven a substantial increase in net weight production results and applying LED for their growth show substantial production increase and lower energy usage and cost of ownership.
  • Other examples are salad growth which need different combinations of Red, Blue and Yellow. Especially designed for leafy greens to give good biomass, taste and nutritional values.

 Multi-layer LED GROW SYSTEMS

PLANTS SEE LIGHT DIFFERENTLY THAN WE DO

Plants have a different sensitivity for light than for example humans.

We are most sensitive to green light, plants have a broader sensitivity for photosynthesis with a preference for blue and red r\light.

Growth light is one of the most important factors driving photosynthesis.

It is the number of photons per second in between 400-700 nm called PAR (Photosynthetic Active Radiation) area, indicated in micromoles/s (µmol)










Light often a main limiting factor in plant growth

WHY LIGHTING IN HORTI CULTURE BESIDES THE SUN?

MORE LIGHT ADDS GROWING POWER

  • higher production and quality



LIGHTING GIVES THE GROWER CONTROL OVER

  • increased flexibility and constant quality
  • Year round production
  • Planning control of production time
